Features:
OOTDTY
Good sealing effect, easy to install.
Make of brass, durable, anti corrosion, high temperature resistant.
Mainly used for water flow switchs control of electric appliances such as water heaters, humidifiers, drinking fountains.
When this product to a load 50W, intermediate must be added, otherwise it cannot be used.
Working method: When there water flow in the water flow switchs and the water flow rate ≥1.5L/min, the in the water flow switchs will receive water. The flow pushes the displacement, and the displacement the source to produces the control effect, so that the water flow switchs output “on” The input to the equipment control system, and the control system realizes the control function. When the water flow less than the starting flow, the water flow switchs outputs a “off” The control system produces the samereverse control.
Specifications:
Material: Brass
Thread: DN20
Inner Diameter: 18mm, Outer Diameter: 26mm
Thread: 15mm
Switching current: 0.5A
Load current: 0.5A
Contact resistance: 100mg
Load power: 50W
Load
Minimum breakdown
Starting water flow: ≤1.5L/MIN
Working water flow
Starting water pressure: ≤0.1Mpa
Withstanding water pressure: ≤1.75Mpa
Operating temperature: 1~120℃
Applicable temperature: -20~150℃
Response time: 0.2S
Release time: 0.2S
Size: Approx. 6.2×3.3x3cm/2.44×1.30×1.18in
Package Includes:
1x Fluidmeter Counter
Note:
Please allow 1-2cm errors due to manual measurement, make sure that you do not mind before you order.
Due to the difference between different monitors, the picture may not reflect the actual color of the item.
