LASER TREE 10W 5W Laser Head with Air Assist TTL Blue Light Module for DIY Laser Cutting Engraving Cnc Machine Wood Tools



Module 1: LT-80W-AA-PRO(10W Optical Power)

Product Features

1. High Power Laser Module— 2-Beam compression technology, 10W optical power laser module

2. Powerful Cutting Ability

Cut 8mm bass plywood: 120mm/min, 100% power, by one pass

Cut 5mm black acrylic: 50mm/min, 100% power, by one pass

Cut 3mm MDF: 150mm/min, 100% power, by 2 passes

3. Professional Air Assist— Blowing through the air nozzle to get clean-cut edges, improve cutting performance



4. Super Fast Engraving Speed— ultra-fast engravingon stainless steel-30mm/s



5. Widely Compatibility— Suitable for Z*aitu,O*tur,Tw* Trees,S*ulpful9, Xtool, A*omstack and other models of DIY laser engraving machines.

Specification:

Material: aluminum alloy

Effect output power: 80W

Optical Power：10W (±1W)

Wavelength: 450nm (±10nm)

Light color: blue

Focus Length: 45mm

Spot form: Punctiform, fixed focus

Electric power: 12V 3.2A(3A-3.5A); 24V 1.7A(1.5A-2A)



PWM Modulation: 0/3-12V 0-5kHz TTL/PWM

Input port: XH2.54-3P socket

Item size: 40*40*147mm

Laser module net weight: 250g

Professional Air Assist

When cutting with this laser head, the air assist system will blow air through the air nozzle.

This will give you a great cutting experience and greatly reduce burn marks.

With Air Assist VS No Air Assist

Blowing through the air nozzle to get clean-cut edges, improve cutting performance

Dual-LDs with Beam Compressed Technology

One laser module has two built-in laser diodes.The optical power of each diode is 5W.

With beam combination technology, our laser module is double powerful and the beam quality is as good as a single diode.

Powerful Cutting Ability:

Minimum 0.08mm Ultra-thin Beam

Ultra-fast engraving on stainless steel-30mm/s

Widely Compatible Design

Suitable for Z*aitu,O*tur,Tw* Trees,S*ulpful9, Xtool, A*omstack and other models of DIY laser engraving machines

Reference Settings for Cutting

For example, if you want to cut 8mmplywood, the focus fixing plateshould be 4mm.

Reference Settings for Engraving

For example, if you want to engrave,the focus fixing plate should be 7mm.

Module 2: LT-40W-AA (5W Optical Power)

Product Features:

1.Beam compression technology, 5W optical power laser module.

2.Excellent Cutting Ability: Cutting 4mm plywood by one pass at a Speed of 190mm/s.

3.Very Fast Engraving Speed: 45mm focal length, engrave 304 stainless steel at speeds up to 6000mm/min.

4.Magnetic eye protective cover: Eye protection and easy disassembly.

5.For various 12V 3PIN laser engraving machines, plug and play. For 12V 4PIN machines, just use the driver adapter to connect.

Beam Compressed Spot
More Precise with 5W Compressed Spot



Air Pump



Description

The air pump is an essential part of the laser module with air assisted.
It provides a steady high-pressure airflow to blow away smoke and obtain clean-cut edges.
In addition, it can improve the efficiency of laser processing and thus save your time.



Features：

1. High-quality materials: metal nozzle, resisting high temperature

2. Large and steady air output: 0-30 L/min adjustable speed, blowing away smoke and residue produced during laser processing

3. Super silent: little noise and vibration in operation

4. Small in size: can be placed on desktop

5. Easy installation: can be easily transformed and upgraded
