Mini YAG Fiber Laser Welding Machine 200W 100J Touch Screen Jewelry Spot Welder With HD CCD Control Built-in Air Cooling System For Gold Silver Chain Ring Pendant Denture Soldering
The jewelry laser welder is specifically for jewelry laser welding of a product,mainly used in gold and silver ornaments of the hole and spot welding blisters. Laser spot welding machine is one of the important aspects of the application
of laser material processing technology. The jewelry laser welding machine’s process is heat conduction. That is, laser radiation heats the surface of the work piece. The heat of the surface spreads through the heat conduction to the
interior. By controlling the width, energy, peak power and repetition of laser pulse Frequency and other parameters, the workpiece melting, forming a specific pool. Because of jewelry laser welding machine’s unique advantages, has been successfully applied to gold and silver jewelry processing and micro, small parts welding.
200W-Mini desktop integrated YAG laser Welding machine manual
Specification
Model:200W-Mini Laser medium
Nd 3+ :YAG
Laser Wavelength 1064nm
Output power200W
Pulse width 0.1~20ms
adjustable Pulse Repeated
Frequency 1~20Hz adjustable
HD CCD System
Maximum single
pulse power 100J
Cooling : Built-in Air cool system
Maximum input power 6KW
Net weight: 35KG
Voltage: 220V/50HZ/3KVA(If 110V country need to use with transformer)
